85A Hardness Polyurethane V Belt with A, B, C, D, M, Z Specification for Drive Transmission in -35 to 80 Temperature Range

最小注文数量 1,000
価格 1

試供品およびクーポンのための私に連絡しなさい。

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

スカイプ: sales10@aixton.com

心配があれば、私達は24時間のオンライン・ヘルプを提供する。

x
商品の詳細
材料 pu 内部素材 pu
硬度 85a 温度範囲 -35-80
硬度を海岸 80a -98a 丸いベルトダイア。 2mmから30mm
Vベルトタイプ A、B、C、D、M、Z タイプX 13mm
タイプh 8mm bタイプx 17mm
bタイプh 11mm CタイプX 22mm
cタイプh 14mm DタイプX 32mm
Dタイプh 19mm
ハイライト

85A Hardness Polyurethane V Belt

,

A

,

B

,

C

,

D

,

M

,

Z Specification PU V Belt

,

Temperature Range -35 - 80 TPU V Belt

メッセージ
製品の説明
Urethane Transmission Red Polyurethane V Belt Supplier
Alkali Resistant Smooth 80A Polyurethane V Belt For Conveyor
TPU V Belts Specifications
High-performance PU V belt with excellent durability and resistance properties.
  • Thermoplastic polyurethane material, easy to be melted jointed
  • Reinforced by Polyester Cord or Steel Cord
  • Temperature range: -35°C to 80°C
  • Shore A hardness range: 80A - 98A
  • Excellent resistance to flex, abrasion resistance, and easy jointing
  • Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics industries
  • Specialized applications in ceramic industry for glaze lines, polishing lines, and transmission lines
Round Belt Specifications
Available in diameters from 2mm to 30mm. Options include:
  • Smooth Belt with good surface finish
  • Rough belt with even surface roughness
V-belt Specifications
Available in A, B, C, D, M, Z types with excellent wear resistance, particularly suited for ceramic industry applications.
Specification X(mm) H(mm) Hardness (Shore A) M/rolls Reinforced
A 13mm 8 90A 30
B 17mm 11 90A 30
C 22mm 14 90A 30
D 32mm 19 90A 30
M 8mm 4 90A 50
Z 10mm 5 90A 50
